| Frame |
Aluminum Frame, 130mm Travel, UDH| R-Wheel Size Adj | Ride Aligned™ |
| Fork |
RockShox Lyrik Select +, 140mm Travel, 44mm offset, Fender Included |
| Rear Shock |
RockShox Super Deluxe Select RT, 210x50mm Std eyelet |
| Headset |
Tapered 1-1/8″- 1.5″,(ZS44/28.6 | ZS56/40) |
| Grips |
WTB Wavelength, 140mm Length |
| Handle Bar |
Norco 6061 DB Alloy, 800mm, 25mm Rise(S1,S2) – 35mm Rise(S3,S4,S5) |
| Stem |
Norco 6061, 40mm Length, 35mm Clamp |
| Seat Post |
TranzX YSI160 RAD+, 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5) |
| Seat Post Clamp |
Norco Alloy Nutted Clamp, 34.9mm ID |
| Saddle |
WTB Solano Med, 142×240 mm, Steel Rails |
| Front Brake |
Shimano SLX BR-M7120 4-P, Metallic pads |
| Front Brake Rotor |
Shimano SM-RT64, 203mm, C-lock |
| Rear Brake |
Shimano SLX BR-M7120 4-P, Metallic pads |
| Rear Brake Rotor |
Shimano RT-64, 180mm, C-lock |
| Brake Levers |
Shimano SLX BL-M7100 |
| Shifter Rear |
Shimano Deore XT SL-M8210-IR, 12sp |
| Rear Derailleur |
Shimano Deore XT RD-M8200, SGS, 12sp |
| Cassette |
Shimano Deore XT CS-M8200-12, 10-51T, 12sp |
| Chain |
Shimano Deore XT CN-M8100, 12sp |
| Crankset |
Shimano Deore FC-M6200, 30T, 55CL, 165mm(S1,S2) – 170mm(S3,S4,S5) |
| Bottom Bracket |
Shimano, BSA 73mm |
| Front Hub |
Shimano HB-TC500-15-B,15x110mm Boost, 32H, C-lock |
| Rear Hub |
Shimano FH-TC600-MS-B, 12x148mm Boost, Micro Spline, 32H, C-lock |
| Rims |
WTB KOM Team i30 TCS 2.0, 30mm, 32H, 29″ |
| Front Tire |
Schwalbe Magic Mary, Trail casing, Ultra Soft , Radial, 29×2.5″ |
| Rear Tire |
Schwalbe Roamy, Trail casing, Soft, Radial, 29×2.4″ |
