| Frame |
|
Aluminum Frame, 130mm Travel, UDH| R-Wheel Size Adj | Ride Aligned™ |
| Fork |
|
RockShox Recon RL 140mm, 44mm Offset |
| Rear Shock |
|
DVO Opal, 210x50mm, Std eyelet |
| Headset |
|
Tapered 1-1/8″- 1.5″,(ZS44/28.6 | ZS56/40) |
| Grips |
|
WTB Wavelength, 140mm Length |
| Handle Bar |
|
Norco 6061 DB Alloy, 800mm, 25mm Rise(S1,S2) – 35mm Rise(S3,S4,S5) |
| Stem |
|
Norco 6061, 40mm Length, 35mm Clamp |
| Seat Post |
|
TranzX YSI34QL , 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5) |
| Seat Post Clamp |
|
Norco Alloy Nutted Clamp, 34.9mm ID |
| Saddle |
|
WTB Solano Med, 142×240 mm, Steel Rails |
| Front Brake |
|
Tektro HD-M535, 4 Piston , Resin Pads |
| Front Brake Rotor |
|
Tektro TR203, 203mm, 2.3mm Thickness, 6-bolt |
| Rear Brake |
|
Tektro HD-M535, 4 Piston , Resin Pads |
| Rear Brake Rotor |
|
Tektro TR203, 180mm, 2.3mm Thickness, 6-bolt |
| Brake Levers |
|
Tektro HD-M535 |
| Shifter Rear |
|
Shimano CUES SL-U6000-10R, 10sp |
| Rear Derailleur |
|
Shimano CUES RD-U6000, 10sp, GS |
| Cassette |
|
Shimano CUES CS-LG300 10sp 11-48T |
| Chain |
|
Shimano LG-500, 10sp |
| Crankset |
|
Shimano CUES FC-U6000-1, 30T, CL55, 165mm(S1,S2) – 170mm(S3,S4,S5) |
| Bottom Bracket |
|
Shimano, BSA 73mm |
| Front Hub |
|
Formula DC-511, 15x110mm Boost, 32h, 6-bolt |
| Rear Hub |
|
Formula DC-3248,12x148mm Boost, HG, 32h, 6-bolt |
| Rims |
|
WTB ST i30 TCS 2.0 ,30 mm, 32H, 29″ |
| Front Tire |
|
Schwalbe Magic Mary, Trail casing, Ultra Soft , Radial, 29×2.5″ |
| Rear Tire |
|
Schwalbe Romy, Trail casing, Soft, Radial, 29×2.4″ |
