| Frame |
|
Aluminum Frame, 130mm Travel, UDH| R-Wheel Size Adj | Ride Aligned™ |
| Fork |
|
RockShox Psylo Gold RC, 140mm Travel, 44mm Offset |
| Rear Shock |
|
RockShox Super Deluxe, 210x50mm Std eyelet |
| Headset |
|
Tapered 1-1/8″- 1.5″,(ZS44/28.6 | ZS56/40) |
| Grips |
|
WTB Wavelength, 140mm Length |
| Handle Bar |
|
Norco 6061 DB Alloy, 800mm, 25mm Rise(S1,S2) – 35mm Rise(S3,S4,S5) |
| Stem |
|
Norco 6061, 40mm Length, 35mm Clamp |
| Seat Post |
|
TranzX YSI34QL , 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5) |
| Seat Post Clamp |
|
Norco Alloy Nutted Clamp, 34.9mm ID |
| Saddle |
|
WTB Solano Med, 142×240 mm, Steel Rails |
| Front Brake |
|
Shimano BR-MT420, Metallic Pads |
| Front Brake Rotor |
|
Shimano SM-RT64, 203mm, C-lock |
| Rear Brake |
|
Shimano BR-MT420, Metallic Pads |
| Rear Brake Rotor |
|
Shimano SM-RT64, 180mm, C-lock |
| Brake Levers |
|
Shimano BL-MT401 |
| Shifter Rear |
|
Shimano Deore SL-M6200-IR, 12sp |
| Rear Derailleur |
|
Shimano Deore RD-M6200, SGS, 12sp |
| Cassette |
|
Shimano Deore CS-M6200-12, 10-51T, 12sp |
| Chain |
|
Shimano Deore CN-M6100, 12sp |
| Crankset |
|
Shimano Deore FC-M6200, 30T, 55CL, 165mm(S1,S2) – 170mm(S3,S4,S5) |
| Bottom Bracket |
|
Shimano, BSA 73mm |
| Front Hub |
|
Shimano HB-TC500-15-B,15x110mm Boost, 32H, C-lock |
| Rear Hub |
|
Shimano FH-TC500-MS-B, 12x148mm Boost, Micro Spline, 32H, C-lock |
| Rims |
|
WTB ST i30 TCS 2.0 ,30 mm, 32H, 29″ |
| Front Tire |
|
Schwalbe Magic Mary, Trail casing, Ultra Soft , Radial, 29×2.5″ |
| Rear Tire |
|
Schwalbe Romy, Trail casing, Soft, Radial, 29×2.4″ |
